Robertshaw ETC-111000-000 | Single Stage Temperature Control, 8' Sensor, 120/240V Input

The Robertshaw ETC-111000-000 Single Stage Electronic Temperature Control is a reliable, easy-to-use solution for heating and cooling applications requiring remote temperature sensing. With an intuitive digital display, this unit allows precise 1°F adjustments of setpoint and differential via a simple keypad interface. The included 8' thermistor sensor supports remote placement up to 400 feet away using standard 22-gauge wire. Diagnostic features continuously monitor system health and provide error codes for troubleshooting. A built-in keypad lockout switch protects settings from unauthorized changes, and an SPDT relay provides flexible control output.

Technical Specifications:

• Capillary Length: 8'
• Temperature Range: -30°F to 220°F
• Voltage: 120V, 208V, 240V
• Enclosure Type: NEMA-1
• Operating Temp Range: -20°F to 140°F
• Width: 2.7"
• Height: 6.52"
• Depth: 2.48"
• Application: Remote Bulb Temperature
• Differential: 1°F to 30°F
• Sensor Type: Thermistor
• Bulb Size: 2" x 1/4"
• Humidity Range: 0 to 95% RH (Non-Condensing)
• Switch Action: SPDT
• Contact Ratings 120V: 16.0 AFL / 96.0 ALR
• Contact Ratings 240V: 8.0 AFL / 48.0 ALR
• Resistive Load: 15A @ 120V / 8A @ 240V
• Pilot Duty Rating: 125 VA
• Horsepower Rating: 1 HP
• Stages: One
