Sporlan C-083-S-HH | Catch-All Filter-Drier, 3/8" ODF Liquid Line

The Sporlan C-083-S-HH Catch-All Filter-Drier is designed to remove moisture, acids, dirt, sludge, and wax from refrigerants. With a blend of desiccants and activated charcoal, it offers high-performance filtration for HVAC and refrigeration systems.

Specifications:

• Model: C-083-S-HH 3/8 Copper Conn
• Capacity: 9 cu in
• Connection Size: 3/8" x 3/8" ODF
• Diameter: 2.62"
• Height: 2.8"
• Length: 7.1"
• Overall Length: 5.25"
• Weight: 1.10 lbs
• Max Pressure: 650 psi

Features:

• Leak-proof shell with copper sweat fittings
• Outlet safety filter
• Blended desiccants for moisture and acid removal
• Activated charcoal for wax removal
• Filters scale, dirt, sludge, and contaminants
• UL Listed
• CAP and T designations for specific installations

Applications:

• Air Conditioning
• Commercial & Low-Temp Refrigeration
• Systems with wax contamination
• Compatible with HCFC and HFC refrigerants
