Sporlan C-164-S-HH | Catch-All Filter-Drier, 1/2" ODF Liquid Line

The Sporlan C-164-S-HH Catch-All Filter-Drier effectively removes moisture, acids, dirt, and wax from refrigerants. With its specially designed HH core, it provides superior filtration for HVAC and refrigeration systems.

Specifications:

• Model: C-164-S-HH 1/2 Copper Conn
• Capacity: 16 cu in
• Connection Size: 1/2" x 1/2" ODF
• Diameter: 3.00"
• Height: 3.1"
• Length: 7.8"
• Overall Length: 6.00"
• Weight: 1.58 lbs
• Max Pressure: 650 psi

Features:

• Leak-proof shell with copper sweat fittings
• Outlet safety filter
• Molded core with blended desiccants for moisture & acid removal
• Activated charcoal for wax removal
• Filters scale, solder particles, sludge, and dirt
• UL Listed
• CAP and T designations for capillary tube system installations

Applications:

• Air Conditioning
• Commercial & Low-Temp Refrigeration
• Systems prone to wax contamination
• Compatible with HCFC and HFC refrigerants
