Sporlan C-305-S | Catch-All Filter-Drier, 5/8" ODF Liquid Line

The Sporlan C-305-S Catch-All Filter-Drier is designed to provide reliable filtration for refrigerant systems, efficiently removing moisture, acid, and contaminants. Its durable construction and advanced desiccant technology ensure the protection and longevity of your HVAC and refrigeration systems.

Specifications:

• Model: C-305-S 5/8 Copper Conn
• Capacity: 30 cu in
• Connection Size: 5/8" x 5/8" ODF
• Diameter: 3.00"
• Height: 3.5"
• Length: 11.5"
• Overall Length: 9.25"
• Weight: 3.05 lbs per unit
• Maximum Operating Pressure: 650 psi

Features:

• Leak-proof shell with solid copper sweat fittings for reliable, durable performance
• Outlet safety filter for additional system protection
• Molded porous core of blended desiccants to maximize moisture and acid removal
• Filters contaminants like scale, solder particles, carbon, sludge, and dirt with minimal pressure drop
• UL Listed for safety and compliance
• Maximum working pressure: 650 psi
• Designed for use with HCFC and HFC refrigerants
• CAP designation for capillary tube systems
• T designation for Schrader-type pressure tap on the inlet

Applications:

• Air Conditioning
• Commercial Refrigeration
• Low Temperature Refrigeration
• Capillary tube systems
• Suitable for all HCFC and HFC refrigerants
